Test Probes
:quality(98)/dehn.at/store/f/50282176/HDVORSCHAU/766960a1_16-9.jpg)
:quality(98)/dehn.at/store/f/50282176/HDVORSCHAU/766960a1_16-9.jpg)
- Safe contact with the part of an installation to be tested
- With M8 thread, to be screwed on test electrodes of PHE4, PHE III and PHE voltage detectors
- For switchgear installations with limited access
- Available in different lengths and angles
Art.-Nr. 766916 PSO M8 PHE
GTIN 4013364106840, Zolltarifnr. (EU): 90309000, Bruttogewicht: 125.00 g, VPE: 1.00 pc(s)
Abbildungen
:quality(98)/dehn.at/store/f/50282180/HDVORSCHAU/766916.jpg)
:quality(98)/dehn.at/store/f/50282180/HDVORSCHAU/766916.jpg)
:quality(98)/dehn.at/store/f/50282181/HDVORSCHAU/766916m_D.jpg)
:quality(98)/dehn.at/store/f/50282181/HDVORSCHAU/766916m_D.jpg)
Technische Daten
| Nominal voltage (UN ) | 1 ... 24 kV |
| Total length (lG ) | 420 mm |
| Length (l1 ) | 300 mm |
| Diameter | 11 mm |
| For use at | ^ |
| Suitable for | PHE4, PHE III, PHE |
Art.-Nr. 766960 PSO M8 PHE L800
GTIN 4013364109629, Zolltarifnr. (EU): 90309000, Bruttogewicht: 310.00 g, VPE: 1.00 pc(s)
Abbildungen
:quality(98)/dehn.at/store/f/50282186/HDVORSCHAU/766960.jpg)
:quality(98)/dehn.at/store/f/50282186/HDVORSCHAU/766960.jpg)
:quality(98)/dehn.at/store/f/50282187/HDVORSCHAU/766960m_D.jpg)
:quality(98)/dehn.at/store/f/50282187/HDVORSCHAU/766960m_D.jpg)
Technische Daten
| Nominal voltage (UN ) | 1 ... 24 kV |
| Total length (lG ) | 890 mm |
| Diameter | 14 mm |
| For use at | _ |
| Suitable for | PHE4, PHE III, PHE |
Art.-Nr. 766940 PSO M8 W25 PHE
GTIN 4013364080485, Zolltarifnr. (EU): 90309000, Bruttogewicht: 145.00 g, VPE: 1.00 pc(s)
Abbildungen
:quality(98)/dehn.at/store/f/50282191/HDVORSCHAU/766940.jpg)
:quality(98)/dehn.at/store/f/50282191/HDVORSCHAU/766940.jpg)
:quality(98)/dehn.at/store/f/50282192/HDVORSCHAU/766940m_D.jpg)
:quality(98)/dehn.at/store/f/50282192/HDVORSCHAU/766940m_D.jpg)
Technische Daten
| Nominal voltage (UN ) | 1 ... 24 kV |
| Total length (lG ) | 450 mm |
| Length (l1 ) | 280 mm |
| Diameter | 11 mm |
| For use at | ^ |
| Suitable for | PHE4, PHE III, PHE |
Art.-Nr. 766941 PSO M8 W45 PHE
GTIN 4013364080478, Zolltarifnr. (EU): 90309000, Bruttogewicht: 150.00 g, VPE: 1.00 pc(s)
Abbildungen
:quality(98)/dehn.at/store/f/50282196/HDVORSCHAU/766941.jpg)
:quality(98)/dehn.at/store/f/50282196/HDVORSCHAU/766941.jpg)
:quality(98)/dehn.at/store/f/50282197/HDVORSCHAU/766941m_D.jpg)
:quality(98)/dehn.at/store/f/50282197/HDVORSCHAU/766941m_D.jpg)
Technische Daten
| Nominal voltage (UN ) | 1 ... 24 kV |
| Total length (lG ) | 395 mm |
| Length (l1 ) | 280 mm |
| Diameter | 11 mm |
| For use at | ^ |
| Suitable for | PHE4, PHE III, PHE |
Art.-Nr. 766950 PSO M8 W90 PHE
GTIN 4013364090668, Zolltarifnr. (EU): 90309000, Bruttogewicht: 339.00 g, VPE: 1.00 pc(s)
Abbildungen
:quality(98)/dehn.at/store/f/50282201/HDVORSCHAU/766950.jpg)
:quality(98)/dehn.at/store/f/50282201/HDVORSCHAU/766950.jpg)
:quality(98)/dehn.at/store/f/50282202/HDVORSCHAU/766950m_D.jpg)
:quality(98)/dehn.at/store/f/50282202/HDVORSCHAU/766950m_D.jpg)
Technische Daten
| Nominal voltage (UN ) | 1 ... 24 kV |
| Total length (lG ) | 200 mm |
| Length (l1 ) | 370 mm |
| Diameter | 20 mm |
| For use at | ^ |
| Suitable for | PHE4, PHE III, PHE |
