DEHNcare APS with Lever
:quality(98)/dehn.at/store/f/50281400/HDVORSCHAU/ArcFit_out_0041_16-9.jpg)
:quality(98)/dehn.at/store/f/50281400/HDVORSCHAU/ArcFit_out_0041_16-9.jpg)
- Fog-free on the inside
- Extremely scratch-resistant
- Chemical-resistant on the outside
- Certified according to PPE regulation (EU) 2016/425
Art.-Nr. 785721 APS CL1 MEHA
GTIN 4013364360198, Zolltarifnr. (EU): 39269060, Bruttogewicht: 192.00 g, VPE: 1.00 pc(s)
VorgängerAbbildungen
:quality(98)/dehn.at/store/f/50281406/HDVORSCHAU/785721.jpg)
:quality(98)/dehn.at/store/f/50281406/HDVORSCHAU/785721.jpg)
Zertifikate
Technische Daten
| Nominal voltage up to (UN ) | 1000 V |
| Colour | Transparent |
| Material | Polycarbonate |
| Wall thickness | approx. 2 mm |
| Arc fault protection class (box test 4 kA / 0.5 s – single-pole) | APC 1 |
| Arc energy (Warc or WLBP ) | 158 kJ |
| Visible light transmittance (VLT) | ≥ 75 % |
| Standard | GS-ET-29, EN 166, EN 170 |
Art.-Nr. 785722 APS CL2 MAHA
GTIN 4013364360242, Zolltarifnr. (EU): 39269060, Bruttogewicht: 294.00 g, VPE: 1.00 pc(s)
Abbildungen
:quality(98)/dehn.at/store/f/50281434/HDVORSCHAU/785722.jpg)
:quality(98)/dehn.at/store/f/50281434/HDVORSCHAU/785722.jpg)
Zertifikate
Technische Daten
| Nominal voltage up to (UN ) | 1000 V |
| Colour | blue |
| Material | polycarbonate |
| Wall thickness | approx. 2 mm |
| Arc fault protection class (box test 7 kA / 0.5 s – single-pole) | APC 2 |
| Arc energy (Warc or WLBP ) | 318 kJ |
| Visible light transmittance (VLT) | ≥ 74.4 % |
| Standard | GS-ET-29, EN 166, EN 170 |
