Connecting Clamps for Foundation Earth Electrodes
:quality(98)/dehn.at/store/f/50304047/HDVORSCHAU/308120a1_16-9.jpg)
:quality(98)/dehn.at/store/f/50304047/HDVORSCHAU/308120a1_16-9.jpg)
For T, cross and parallel connections, without having to insert the conductor.
Arrangement:
(II) = parallel
(+) = cross
Art.-Nr. 308120 VK EH R10 F30 ST
GTIN 4013364099258, Zolltarifnr. (EU): 85359000, Bruttogewicht: 138.10 g, VPE: 25.00 pc(s)
:quality(98)/dehn.at/store/f/50304059/HDVORSCHAU/308120.jpg)
:quality(98)/dehn.at/store/f/50304059/HDVORSCHAU/308120.jpg)
:quality(98)/dehn.at/store/f/50304060/HDVORSCHAU/308120m_D.jpg)
:quality(98)/dehn.at/store/f/50304060/HDVORSCHAU/308120m_D.jpg)
Technische Daten
| Material | St/tZn |
| Clamping range Rd / Fl | (II) 10 / 30 mm |
| Clamping range Fl / Fl | (+/II) 30 / 30 mm |
| Standard | EN 62561-1 |
| *) For exact assignment see test certificate. | |
Art.-Nr. 308129 VK EH R10 F30 V2A
GTIN 4013364099265, Zolltarifnr. (EU): 85359000, Bruttogewicht: 134.80 g, VPE: 25.00 pc(s)
:quality(98)/dehn.at/store/f/50304070/HDVORSCHAU/308129.jpg)
:quality(98)/dehn.at/store/f/50304070/HDVORSCHAU/308129.jpg)
:quality(98)/dehn.at/store/f/50304071/HDVORSCHAU/308120m_D.jpg)
:quality(98)/dehn.at/store/f/50304071/HDVORSCHAU/308120m_D.jpg)
Technische Daten
| Material | StSt |
| Clamping range Rd / Fl | (II) 10 / 30 mm |
| Clamping range Fl / Fl | (+/II) 30 / 30 mm |
| Standard | EN 62561-1 |
| *) For exact assignment see test certificate. | |
